| MF 385 4WD PERFORMANCE: |
|
Max. Engine power @ 2,200 rpm
Max. Torque at 1,600 engine rpm
Max. PTO power at 2,200
Engine rpm
*Certified to BS AU 141a
** Manufacturer’s Estimate |
85 hp*
291 Nm
70 hp**
|
| |
|
MF 385 4WD ENGINE:
Make/Type
No. of Cylinders
Injection
Bore
Stroke
Capacity
Aspiration
Compression Ratio
Starting Aid
Throttle Control
Cooling
Air Cleaner Type
Air Pre-Cleaner
Fuel Filter
Exhaust
Oil Cooler
|
Perkins / 4.41
4
Direct
101 mm
127 mm
4.1
Natural
15.3:1
Thermostart
Hand and Foot
Water
Oil Bath
Over bonnet air swirl
Dual high capacity
With sedimentor
Vertical; muffler
under bonnet
Water Cooled |
| |
|
| MF 385 4WD ELECTRICS: |
|
Voltage
Battery
Alternator/Starter
|
12V, Negative Earth
96 Ah
45 A/2.8 KW
|
| |
|
| MF 385 4WD CLUTCH: |
|
Type
Diameter
Lining Material
|
Dual
305x254 mm
Cerametallic
|
| |
|
| MF 385 4WD POWER TAKE - OFF: |
|
Type
Engine Speed at 540 PTO rpm
Shaft Diameter
No. of Splines
|
Live
1,789 rpm
35 mm
6
|
| |
|
| MF 385 4WD TYRES: |
|
Front 7.50-16 (6PR)
Rear 18.4 / 15-30 (6PR)
|
7.50-16 (6PR)
18.4 / 15-30 (6PR)
|
| |
|
| MF 385 4WD TRACK ADJUSTMENT: |
|
Front Axle
Rear Axle
|
1,376 - 1,944 mm
1,423-2,134 mm
|
| |
|
| MF 385 4WD STEERING: |
|
| Type |
Hydrostatic
|
| |
|
| MF 385 4WD TRANSMISSION: |
|
Type
Number of Gears |
Sliding spur
8 Forward, 2 Reverse |
Road speed at 2,200 engine rpm with
18.4/15-30 rear tyres |
Gear Speed
Forward 1
Forward 2
Forward 3
Forward 4
Forward 5
Forward 6
Forward 7
Forward 8
Reverse 1
Reverse 2 |
(km/hr)
2.7
3.7
5.1
6.8
10.4
15.2
20.8
27.9
3.5
14.1 |
| |
|
| MF 385 4WD HYDRAULICS: |
|
Function
Pump Type
Maximum Out put
Maximum lift capacity
with Lower links
horizontal
Maximum pressure
Lower links
|
Draft , Position & Response
Control, Constant pumping
4 Piston, Ferguson pump
16.7 liters / min
2,145 kg
21 MPa (205 bars) at Normal
Operating Temperature
Category I & II
Interchangeable balls |
|
| 4WD FRONT AXLE: |
|
Axle Type
Engagement
|
Parallel Drive
Mechanical
|
| |
|
| MF 385 4WD REAR AXLE & BRAKES: |
Axle Type
Brake Type
Brakes Area
Brakes Actuation
Parking Brakes
|
Straddle with epicyclic
reduction
Oil immersed, multi - disc
1,774 Sq. cm.
Hydraulic
Hand Lever Operated
|
| |
|
| MF 385 4WD CAPACITIES: |
Fuel Tank
Engine Sump
Air Cleaner Oil Bath
Cooling System
Hydraulic System
Power Steering Reservior
4WD Front Axle Differential
Hub each Side |
108 lit
7.5 lit
0.7 lit
15.2 lit
47.4 lit
2 lit
5.6 lit
1 lit
|
| |
|
| MF 385 4WD INSTRUMENTATION: |
Gauges
Warming Lights |
Tachometer, Hourmeter,
Fuel lever,
Water Temperature
Battery Condition Direction Indicators
Electric Charge,
Headlight Main Beam,
Low Engine Oil Pressure,
4WD Indication Lights
|
| |
|
| MF 385 4WD WEIGHT & DIMENSIONS: |
with 12.4-24 Front & 18.4/15-30 Rear Wheel with
Full Fuel, Oil & Water
|
Weight Front
Weight Rear
Weight Total
Dimensions
Overall Length
Width (minimum)
Wheel Base
Height
Over Exhaust
Over Steering Wheel
Turning Circle
Without Brakes
Ground Clearance
Under Gearbox
Under 4WD Front Axle
|
1,429 kg
1,582 kg
3,011 kg
3,810 mm
1,871 mm
2,350 mm
2,485 mm
1,781 mm
8,518 mm
501 mm
395 mm
|
| |
|
| MF 385 4WD STANDARD EQUIPMENT: |
Weight Frame without Weights
Standard Tool Box with Set of Tools
Top Link
Cat-I & II Balls
Check Chains
Chain Stablisers
Spring Suspension Seat
Flat Top Fenders &
Operator’s Manual |
| |
|
| MF 385 4WD OPTIONAL EQUIPMENT / ACCESSORIES: |
Cabin (A/C or Non-A/C)
Sun Canopy (ROPS Style)
Front Ballast/Weights
Adjustible Pintle Hook, Simple Pintle Hook
Swinging Drawbar, 9 Hole Drawbar
Auto Hitch
Hydraulic Control Outlets/Spool Valves
External Electric Switch
PTO Belt Pulley &
International Warranty Tool Kit |
|
|
